The CD/NC Series C-frame hydraulic presses, available in 50 to 150 tons, are engineered for stamping, die cutting, and forming while offering exceptional adaptability. This series features a top adaptable piston and a bolster table with DIN-650 T-slots, making it versatile for a wide range of tooling setups and applications. Constructed from S355JR steel and operating at 320 BAR, these presses ensure superior durability and precision.
With programmable operations powered by SIEMENS PLC control, the CD/NC Series provides precise control over power, stroke, and dwell time, making it ideal for both standalone and automated production environments.
The CD-50 C-Frame Hydraulic Press is engineered for precision tasks such as stamping, die-cutting, and forming. With a 50-ton capacity, this press combines robust performance with a compact design, making it ideal for small to medium-scale industrial applications. Its electro-welded S355JR steel structure ensures durability and precision, while the motorized hydraulic system guarantees efficient and seamless operation.
Equipped with a double-acting cylinder and chrome-plated piston, the CD-50 features a two-speed motorized hydraulic group. The system includes a decompression valve and ensures smooth operation with minimal maintenance. Its low-pressure operation (< 320 BAR) extends the life of the hydraulic components.
The CD-50 features a Siemens safety PLC and a 4″ MTP-400 touchscreen for intuitive programming. Operators can adjust power, stroke, and dwell time easily. Safety measures include fixed side protections, photoelectric barriers, and a two-handed safety push button, all compliant with CE standards.
The system comes equipped with a pivoting control panel featuring an NC Siemens MTP-700 touchscreen. This interface allows users to program settings such as power, cylinder stroke, and operating speeds. It includes storage for up to 300 working cycle configurations.
Both electrical and hydraulic operations are designed to be redundant and self-regulated, featuring an additional safety block and automated safety mechanisms. The system ensures compliance with safety standards by including verification and certification of proper functioning and maintaining safe distances for photocells.
The press operates via low-voltage electric pedals and features enhanced safety measures, including side guards made of polycarbonate, interior LED lighting, and advanced level IV photoelectric sensors on the front.
Optional features include a hydraulic cushion or ejector for added functionality. The system is provided with a glycerin pressure gauge (displayed in tonnes), hydraulic oil, and a detailed instruction manual. All components meet the strict health and safety standards outlined in the EC regulations.
Enhance your CD-50 press with optional features such as extended vertical light options (600mm or 800mm), a hydraulic ejector, Industry 4.0 compatibility, and remote access capabilities. These accessories allow customization to meet your unique operational needs.
Industry 4.0 represents the integration of advanced digital technologies, smart automation, and interconnected systems into manufacturing processes. At Press Machinery Company International, our presses are designed to support Industry 4.0 compatibility, ensuring seamless integration with smart factory environments. This innovation empowers businesses to achieve greater efficiency, precision, and adaptability in their operations.
| Model | CD-5E/NC | CD-15E/NC | CD-30E/NC | CD-50/NC | CD-80/NC | CD-100/NC | CD-150/NC |
|---|---|---|---|---|---|---|---|
| Power (t) | 5 | 15 | 30 | 50 | 80 | 100 | 150 |
| Motor Power (kW) | 0.75 | 1.5 | 3 | 4 | 4 | 13 | 13 |
| Throat Depth (mm) | 125 | 150 | 225 | 265 | 290 | 325 | 375 |
| Working Speed (mm/s) | 2 – 8 | 2 – 10 | 2 – 10 | 6.3 | 5.7 | 4 - 9 | 3 - 7 |
| Approaching Speed (mm/s) | – | – | – | 30 | 28 | 40 | 28 |
| Return Speed (mm/s) | 11 | 13.4 | 12.5 | 42 | 40 | 62 | 40 |
| Maximum Pressure (bar) | 160 | 195 | 195 | 320 | 320 | 320 | 320 |
| Piston Stroke (mm) | 100 | 100 | 150 | 250 | 250 | 250 | 250 |
| Lower Table (mm) | 225 x 200 | 325 x 255 | 325 x 325 | 450 x 450 | 500 x 500 | 550 x 550 | 650 x 650 |
| Max. Vertical Light (mm) | 200 | 275 | 325 | 400 | 400 | 400 | 400 |
| Working Height (mm) | – | – | – | 850 | 850 | 900 | 950 |
| Total Front (mm) | 650 | 750 | 750 | 740 | 780 | 850 | 900 |
| Total Lateral (mm) | 400 | 500 | 750 | 1170 | 1330 | 1470 | 1660 |
| Total Height (mm) | 1350 | 1500 | 2000 | 2080 | 2090 | 2155 | 2295 |
| Weight (kg) | 350 | 500 | 750 | 1480 | 1750 | 2500 | 3750 |
